Description
TECHNICAL DATA
■Length 395mm
■Width 244mm
■Height 120mm
■Wheelbase 260mm
■Front Tread 208mm
■Rear Tread 208mm
■Weight 1,600g (approx.)
■Tires (F/R) φ82×36mm
■Motor 540 class size (sold separately)
■Gear ratio 9.24 : 1
KIT CONTENT
●Kit chassis
●Decals
●L-shaped hexagon wrench
●Cross wrench
●Shock wrench
●Shock oil
●Grease
REQUIREMENT TO RUN
●2 channel R/C system (servo x 1, ESC x 1)
●540 motor (27T-20T recommended)
Brushless motor specifications: No.37031 Le Mans 240S Brushless motor 19.5T, No. 37051 Le Mans 240S ESC (60A/MAX 13.5 turn)
Brushed motor specifications: No.37021 Le Mans brushed motor 30T, No. 82245 KA060-91W ESC
●Battery (7.2V Nickel Hydrogen battery or 7.4V Li-Po battery)
●Battery charger (DC 12V regulated power supply)
●Paint tools for body painting
●Batteries for transmitter
●Tools (1.5/2.0/3.0mm hex wrench screwdriver, needle nose pliers, curved scissors, cutter. When replacing servo horn Phillips screwdriver may be required)
